FR1 PCB Board is Ultra-Economical Paper-Phenolic Boards for High-Volume, Low-Voltage Electronics

What Exactly Is FR-1?

FR-1 is an IPC-4101 /21 & /22 laminate based on paper reinforcement (cellulose fibres) impregnated with phenol-formaldehyde resin. A thin copper foil is bonded to one side, creating a rigid yet extremely punch-friendly PCB core.

Property	Typical Value*	Design Significance
Dielectric constant ε<sub>r</sub> (1 MHz)	≈ 5.1	Acceptable to ≈ 30 MHz analog or ≤10 MHz digital
Loss tangent (1 MHz)	0.03	Low-frequency power & control circuits
Glass-transition temp T<sub>g</sub>	125 – 135 °C	Survives Sn-Pb wave; Pb-free reflow NOT permitted
Z-axis CTE (below T<sub>g</sub>)	75–90 ppm / °C	Keep aspect ratio ≤ 6 : 1 to avoid via cracks
Thermal conductivity	0.25 W / m·K	Derate high-current traces; add jumpers if >1 A
UL-94 flame class	HB (V-0 grades available on request)	Define if appliance safety is mandatory

* Confirm the exact datasheet grade for production.

HIGHPCB is one of the largest Epoxy PCB Board and Rigid PCB manufacturing factories in China, click on the link to see more.

Why Pick Single-Layer FR-1?

Lowest raw-laminate cost

~60 % of FR-4 → unbeatable BOM for toys, chargers, give-away gadgets

Light weight

Paper core ~15 % lighter than FR-4 of the same thickness

One-shot punching

Entire outline, I/O slots & keyholes die-cut in milliseconds

Sufficient insulation

CTI ≥ 150 V – suitable for 120/230 V appliances with correct creepage

Easy V-scoring & singulation

Minimal burr, no fibre pull-out

Key limitations

Cannot withstand Pb-free reflow (≥ 245 °C).
Lower mechanical strength – avoid heavy transformers or press-fit stakes.
Higher dielectric constant – not recommended above ~30 MHz.

highpcb is one of the largest PCB assembly factories in China, click here to see more.

Typical FR-1 Applications

Battery-powered toys, greeting-card sound modules
Wall-plug chargers and small SMPS primary boards ≤ 15 W
IR remote controls, RF key fobs (AM ≤ 27 MHz)
LED night-lights, novelty lamps
Disposable medical strips, glucose-meter test cards

FR-1 Manufacturing Flow

Step	Process Detail	Critical Parameter
CAM & tooling	Punch map, panel utilisation	Clearance ≥ 0.25 mm
Punch / drill	Steel-rule die for outline, carbide bits < 1 mm	≤ 200 hits per bit
Copper imaging & etch	Dry-film or screen resist + alkaline etch	Min trace/space 0.25 / 0.25 mm
Solder mask	Epoxy LPI (green) or blue peelable	Mask opening ≥ 0.10 mm
Surface finish	OSP (low cost) or Sn-Pb hot air; tin ≥ 8 µm	Ensure dwell < 6 s @ 245 °C
Depanelisation	Hydraulic punch	Burr ≤ 0.05 mm
Electrical test	Flying-probe + 250 V HiPot	Isolation ≥ 10 MΩ

Design Guidelines (Engineer’s Quick Sheet)

Board thickness: 1.2 mm or 1.6 mm; thinner boards may warp.
Copper weight: 35 µm standard; 50 µm for ≤ 2 A traces, add 2 mm width per amp.
Pads & annular rings: ≥ 0.30 mm; square pads resist peel-off.
No plated through-holes: Use wire jumpers, rivets or solder bridges for cross-overs.
Thermal relief: 4-spoke, spoke ≥ 0.30 mm to prevent cold solder joints.
Creepage / clearance: 2.5 mm for 250 V basic insulation (IEC 60335-1).

Power tip: add a thick-copper jumper or external Al heat-slug under TO-220 devices, as FR-1’s 0.25 W/m·K conductivity limits heat spreading.

FR-1 vs. FR-2 vs. CEM-1 vs. FR-4 (Single Layer)

Metric	FR-1	FR-2	CEM-1	FR-4
Relative cost	0.4	0.45	0.7	1.0
Punchability	Excellent	Excellent	Excellent	Moderate
Pb-free reflow	✖	✖	Borderline	✔
Wave solder (Sn-Pb)	Good	Good	Good	Excellent
Mechanical strength	Low	Low-Medium	Medium	High
Flame rating	HB (V-0 opt.)	HB	V-0	V-0
